200G QSFP56

Zhaolong QSFP56 or 200G BASE-CR4 (Quad Small Form-Factor Pluggable 56) Copper Cable Assemblies products are designed to meet the needs of Data Centers, Networks, and High-Performance Computing (HPC) applications and have a high-density and transmission rate of 200 Gbps.
Quantity:
  • 200G QSFP56

Product Category

QSFP56  to  QSFP56  200G DAC QSFP56 to QSFP56 200G ACC Redriver Cable QSFP56 200G to 2*QSFP 100G DAC QSFP56 100G to 4*SFP56 50G DAC

Features and Benefits
Compliant with IEEE 802.3cd (200GBASE-CR4) Standard
Compliant with IEEE 802.3bj (100GBASE-CR4) Standard
Compliant with IEEE 802.3by (25 Ethernet) Standard
Data Rate : 25 Gbps/Channel Total Bandwidth 200 Gbps( 4X 50G)
Interface Compliant with SFF 8665 QSFP 28 Gb/s 4X Pluggable Transceiver Solution
Low Power Consumption < 0.5W (Passive)
Support Wire AWG : 32/ 30 / 28 / 26
Support Length (Passive DAC) : 0.5- 3.5 Meter
Support Length (Redrive ACC): 1.0-6.0 Meter
EEPROM signature can be customized


Target Market
200G Ethernet
4x InfiniBand™  EDR,HDR
Fibre Channel
Storage, Switch, & RAID Systems
High-Performance Computing (HPC)
Network Interface Cards (NIC's)
Telecommunication Equipment
Data Center and Enterprise Storage Systems
