UL Style 1354

characteristic
The product has excellent bending resistance, twisting resistance, electromagnetic interference resistance and superior transmission performance. The product has wide application field, strong adaptability, good heat resistance, flame resistance and atmospheric resistance, and can work stably in the environment temperature of - 55 ℃ - 250 ℃.
Availability:
Quantity:
  • UL Style 1354

  • zhaolong

APPLICATIONS

This product can replace the electronic flat line, printing soft board, and is widely used in the internal data transmission of the new generation of notebook computers, LCD displays, handheld game machines, precision medical devices and other micro electronic equipment. At the same time, it can also be used in aerospace, intelligent robots, military and other special fields with good environmental adaptability and reliability.


GENERAL PRODUCT CHARACTERISTICS

Impedance:

90 Ω, 100 Ω

Rated temperature / voltage:

80 ℃ / 30V

Reference standard:

UL758

The conductor is stranded tinned copper or silver tinned copper alloy

PFA is used for insulation

The shield is wound with silver plated copper or tin plated copper alloy Copper foil and color layer pet tape sheath Material complies with ROHS standard
