SFP+ 10G AOC

10G SFP+ AOC is a high data rate parallel active optical cable. It uses high reliability 850nm VCSEL technology to overcome the bandwidth limitation of traditional copper cables. The transmission distance of OM3 multimode fiber can reach 150m.

Quantity:
  • SFP+ 10G AOC
  • zhaolong

Product Category

SFP+ 10G AOC

QSFP+ 40G AOC

SFP28 25G AOC

QSFP28 100G AOC

Features and Benefits
10Gb/s serial optical interface
850nm VCSEL and PIN receiver
Support 10 Gb/s transmission distance up to 150 meters with OM2/OM3 fiber
Operating case temperature 0℃ to +70℃
3.3V power supply voltage
Compliant with SFP+ MSA and SFF-8432 standard
Supports serial ID functionality thru EEPROM
Support digital diagnostics monitoring for module temperature, Vcc, Rx input power, Tx_Disable and Rx_LOS
Typical power consumption 200mW
RoHS Compliance


Target Market
10 Gigabit Ethernet
4G and 8G Fiber Channel applications
1x InfiniBand QDR, DDR, SDR
Storage, Switch, & RAID Systems
High-Performance Computing (HPC)
Network Interface Cards (NIC's)
Telecommunication Equipment
Data Center and Enterprise Storage Systems
