LONGFLEX® SERVO FD 318 CY

Applications
Can be used as connecting cables between motor and converter, or controller and motor of CNC machine tools, robots and other automation equipment. Intended for the place with serious electrical interference. It is very suitable for drag chain or frequent movement in high temperature environment.
Quantity:
  • SERVO FD 318 CY
  • zhaolong

TECHNICAL PARAMETERS

—Temperature Range

    Fixed Application: -40°C~105°C

    Occasional Movement: -5°C~105°C

—Test Voltage

    core/core: 4000V/min(AC)

    core/shield: 4000V/min(AC)

—Insulation Resistance (20°C)

    ≥20MΩ.km

—Rated Voltage

    UL/CSA600V

    IEC/VDE≤0.5mm2:300/500V

                 >0.5mm2:450/750V

—Minimum Bending Radius

    Fixed Application: 4D(D=Cable diameter)

    Mobile Application: 7.5D(D=Cable diameter)

—Technical certification

    UL2586

—Application of Drag Chain

    3~8 million times



CABLE CONSTRUCTION

Conductor:

Ultra-fine stranded bare copper, in line with IEC 60228/VDE 0295 class 6

Insulation:

PVC

Insulation Color:

According to DIN VDE 0293, black cores with white numbering, green-yellow conductor

Inner Jacket:

PVC

Shield:

Control pair tinned copper braiding, tinned copper overall braiding

Jacket:

PVC

Color:

Gray (similar to RAL 7001)


FEATURES

Flame retardance according to VW-1/FT1

Good flexibility and small bending radius

Excellent resistance to external electromagnetic interference

Good oil resistance

Excellent heat resistance
