LF-DATA LiYY
zhaolong
TECHNICAL PARAMETERS
—Temperature Range
Fixed Application : -40℃~80℃
Occasional Movement : -5℃~70℃
—Test Voltage
<0.25mm²=1200V/min(AC)
≥0.25mm²=1500V/min(AC)
—Capacitance
core/core approx 120nF/km
—Insulation Resistance( 20℃)
≥200MΩ.km
—Rated Voltage
0.14mm²=350V
>0.14mm²=500V
—Minimum Bending Radius
Fixed Application : 4D (D=cable diameter)
Occasional Movement : 10D (D=cable diameter)
CABLE CONSTRUCTION
Conductor:
Ultra-fine stranded bare copper, according to IEC 60228/VDE 0295
Insulation:
PVC
Insulation Color:
According to DIN 47100
Jacket:
PVC
Color:
Grey(similar to RAL7035)
features
Flame resistance according to IEC60332-1
Good property of flexibility
Small bending radius
Conditional oil resistance
TECHNICAL PARAMETERS
—Temperature Range
Fixed Application : -40℃~80℃
Occasional Movement : -5℃~70℃
—Test Voltage
<0.25mm²=1200V/min(AC)
≥0.25mm²=1500V/min(AC)
—Capacitance
core/core approx 120nF/km
—Insulation Resistance( 20℃)
≥200MΩ.km
—Rated Voltage
0.14mm²=350V
>0.14mm²=500V
—Minimum Bending Radius
Fixed Application : 4D (D=cable diameter)
Occasional Movement : 10D (D=cable diameter)
CABLE CONSTRUCTION
Conductor:
Ultra-fine stranded bare copper, according to IEC 60228/VDE 0295
Insulation:
PVC
Insulation Color:
According to DIN 47100
Jacket:
PVC
Color:
Grey(similar to RAL7035)
features
Flame resistance according to IEC60332-1
Good property of flexibility
Small bending radius
Conditional oil resistance
